Rainscreen DTM-03 Hook-On Secret Fix
Introducing a state-of-the-art fully secret-fixed system that achieves an impeccably flat and precise aesthetic, characterized by the absence of visible fixings. This system is designed to accommodate a diverse range of panel shapes and configurations, providing unparalleled flexibility in executing intricate aesthetic design techniques.
Delivered as a comprehensive system in component form, the need for on-site fabrication is eliminated, streamlining the installation process. The autonomy of individual panels allows for efficient installation around service areas, while the capability for individual demounting enhances ease of maintenance and repair.
Highlighting adaptability, the system features variable joint sizes, offering a spectrum of joint profile details and treatment options to align with specific project requirements. Comprising five fundamental mullions ranging from 50mm to 150mm in depth, these mullions can be seamlessly installed on virtually any sub-structure or frame, with the potential to span from floor to floor as necessary.
An exceptional feature of this system is its lack of a specific installation start point. Panels can be fitted at random, if desired, owing to the unique panel carrier, which is fully adjustable and easily lockable and unlockable.
In terms of fire performance, rigorous testing by Warringtonfire has resulted in a classification of A1 to EN 13501-1 for 3mm aluminium with no applied coating or with an anodized coating. Additionally, the system achieves a classification of A2-s1, d0 to EN 13501-1 for 3mm aluminium with a PPC coating, underscoring its dedication to safety and adherence to industry standards.
